PIPE & FITTINGS

table
Nominal Pipe Size Outside Diameter (mm) Nominal Wall Thickness Schedule
NPS DN OD SCH
5S		 SCH
10S		 SCH
10		 SCH
20		 SCH
30		 SCH
40S		 SCH
STD		 SCH
40		 SCH
60		 SCH
80S		 SCH
XS		 SCH
80		 SCH
100		 SCH
120		 SCH
140		 SCH
160		 SCH
XXS
1/8 6 10.3 1.24 1.73 1.73 1.73 2.41 2.41 2.41
1/4 8 13.7 1.65 2.24 2.24 2.24 3.02 3.02 3.02
3/8 10 17.1 1.65 2.31 2.31 2.31 3.20 3.20 3.20
1/2 15 21.3 1.65 2.11 2.77 2.77 2.77 3.73 3.73 3.73 4.78 7.47
3/4 20 26.7 1.65 2.11 3.87 3.87 3.87 3.91 3.91 3.91 5.56 7.82
1 25 33.4 1.65 2.77 3.38 3.38 3.38 4.55 4.55 4.55 6.35 9.09
11/4 32 42.2 1.65 2.77 3.56 3.56 3.56 4.85 4.85 4.85 6.35 9.70
11/2 40 48.3 1.65 2.77 3.68 3.68 3.68 5.08 5.08 5.08 7.14 10.15
2 50 60.3 1.65 2.77 3.91 3.91 3.91 5.54 5.54 5.54 8.74 11.07
21/2 65 73 2.11 3.05 5.16 5.16 5.16 7.01 7.01 7.01 9.53 14.02
3 80 88.9 2.11 3.05 5.49 5.49 5.49 7.62 7.62 7.62 11.13 15.24
31/2 90 101.6 2.11 3.05 5.74 5.74 5.74 8.08 8.08 8.08
4 100 114.3 2.11 3.05 6.02 6.02 6.02 8.56 8.56 8.56 11.13 13.49 17.12
5 125 141.3 2.77 3.40 6.55 6.55 6.55 9.53 9.53 9.53 12.70 15.88 19.05
6 150 168.3 2.77 3.40 7.11 7.11 7.11 10.97 10.97 10.97 14.27 18.26 21.95
8 200 219.1 2.77 3.76 6.35 7.04 8.18 8.18 8.18 10.31 12.70 12.70 12.70 15.09 18.26 20.62 23.01 22.23
10 250 273.1 3.40 4.19 6.35 7.80 9.27 9.27 9.27 12.70 12.70 12.70 15.09 18.26 21.44 25.40 28.58 25.40
12 300 323.9 3.96 4.57 6.35 8.38 9.53 10.31 14.27 12.70 12.70 17.48 21.44 25.40 28.58 33.32 25.40 25.40
14 350 355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 12.70 19.05 23.83 27.79 31.75 35.71
16 400 406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.70 16.66 12.70 21.44 26.19 30.96 36.53 40.49
18 450 457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 12.70 23.83 29.36 34.93 39.67 45.24
20 500 508 4.78 5.54 6.35 9.53 12.70 9.53 15.09 20.62 12.70 26.19 32.54 38.10 44.45 50.01
22 559 4.78 5.54 6.35 9.53 12.70 9.53 22.23 12.70 28.58 34.93 41.28 47.63 53.98
24 600 610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 12.70 30.96 38.89 46.02 52.37 59.54
26 660 7.92 12.70 9.53 12.70
28 700 711 7.92 12.70 15.88 9.53 12.70
30 762 6.35 7.92 7.92 12.70 15.88 9.53 12.70
32 800 813 7.92 12.70 15.88 9.53 17.48 12.70
34 884 7.92 12.70 15.88 9.53 17.48 12.70
36 900 914 7.92 12.70 15.88 9.53 19.05 12.70
38 965 9.53 12.70
40 1000 1016 9.53 12.70
42 1100 1118 9.53 12.70
44 1000 1118 9.53 12.70
46 1168 9.53 12.70
48 1200 1219 9.53 12.70
